Product Type: PSC (Permanent Split Capacitor)

HP: 1/6

RPM: 825

Volts: 208-230

Amps: 0.9

Hz: 60

Phase: 1

Frame: 48Y

Enclosure Type: ODP (Open Dripproof)

Mounting: Band/Ring/Stud

Motor Diameter: 5-5/8"

Shaft Diameter: 1/2"

Shaft Length: 6"

Rotation: Reversible

Number of Speeds: 2

Service Factor (SF): 1.00

Bearings: Sleeve

Thermal Protection: Automatic

Maximum Ambient Temperature: 60° C

Insulation Class: B

Duty Cycle: Continuous

Capacitor: 5MFD @ 370VAC Required

FS1018 is listed in Century's cross reference as a possible substitute for the following: Carrier/BDP HC37ML703, A.O. Smith F48C78A01, A.O. Smith F48SD8MA3, A.O. Smith F48SJ68L2, A.O. Smith F48SJ8L1, A.O. Smith F48SJ8L2, A.O. Smith F48SJ8L3, Carrier/BDP P251-5603, Carrier/BDP P251-5802, Carrier/BDP P251-6505, Emerson 8673, Carrier/BDP HC35VB230

Has Reversing Plug

Has Hex Mounting Hub On Both Ends For Cradle Base Mounting

Energy Efficient
